Manhattan HDMI over Ethernet Video Extender via Cat6 1080p 50m Black

Extend a high-definition signal easily over an Ethernet cable. The Manhattan HDMI over Ethernet Extender Kit is the ideal solution for connecting virtually any HDMI source (PlayStation, Xbox, Blu-ray player, satellite receiver, digital recorder, etc.) to a display or projector up to 50 m (164 ft.) via a single Cat6 Ethernet cable. These HDMI extenders provide reliable 1080p video resolution and multi-channel audio transmission over longer distances than HDMI cables alone.

Extend a high-definition signal easily over an Ethernet cable. The Manhattan HDMI over Ethernet Extender Kit is the ideal solution for connecting virtually any HDMI source (PlayStation, Xbox, Blu-ray player, satellite receiver, digital recorder, etc.) to a display or projector up to 50 m (164 ft.) via a single Cat6 Ethernet cable. These HDMI extenders provide reliable 1080p video resolution and multi-channel audio transmission over longer distances than HDMI cables alone. In addition, the transmission module has an additional output port so that a second monitor can be placed in a control cabinet or run to the second screen. It also includes a wideband IR blaster and receiver for remote control of the source device. Flexible Solution for Many A/V Applications Ideal for trade shows, classrooms, video conferencing, presentations and distribution applications, the Manhattan HDMI over Ethernet Extender Kit speeds up and extends a 1080p signal up to 50 m (164 ft.) for convenient display or projector placement. Cat6 Ethernet cabling — UTP, SSTP or SFTP (cables not included) — is less expensive and easier to install than HDMI cable and in-line signal repeaters. When used with our HDMI over Ethernet extender, a clear, crisp, and vivid image over longer distances is achieved. Quality Construction and Easy Installation HDCP compliant with HDMI, HDCP and DVI 1.0, this HDMI over Ethernet Extender Kit is tested to ensure performance and reliability, and installs easily without running software or installing additional hardware.

Technical Specifications

General Features
Brand	Manhattan
Item	Extender
Color	Black
Standards and Certifications	• HDCP • DVI 1.0 • CTS 1.2 • CE • FCC • RoHS2
Cat6 Cable 1080p	at 50 m (165 ft.)
Cat6 Cable 720p	at 70 m (230 ft.)
Cat6 Cable 480p	at 100 m (300 ft.)
Power	5 VDC / 1 A; cable, 1.4 m (4.5 ft.)
Connections	• Two HDMI female (transmitter) • One HDMI female (receiver) • One RJ45 female (transmitter/receiver) • One DC power / 5V female (transmitter/receiver) • One 3.5 mm / IR female (transmitter/receiver)
Video Input Signal	0.5 – 1.0 V p-p
DDC Input Signal	5 V p-p (TTL)
Maximum Single Link Range	1920x1200/60 Hz, 1080p
Video Output:	HDCP 1.2, DVI 1.0
Frequency:	2.25 Gbps / 225 MHz
Video Resolutions	• VGA: 640 x 480, 800 x 600, 1024 x 768, 1920 x 1200 • DTV/HDTV: 480i/480p/576i/576p/720p/1080i/1080p
Dimensions	8.1 cm x 6.2 cm x 2.6 cm
Weight	0.583 kg
