Manhattan PCI Express 4-Port Serial Card DB9

Compatible with most RS232 peripherals, Manhattan's PCI Express Serial Card with 5V power output includes an adapter that allows you to connect up to four independent serial devices — modems, barcode scanners, printers, and more — through a single PCI card. It is ideal for point-of-sale applications as it helps eliminate power supplies from other connected peripherals, reducing clutter and improving reliability. Its high-speed 16C950 UART DB9 serial COM ports are fully compatible with PCI IRQ sharing, even if accessed simultaneously, to help save valuable resources for other expansion cards.

Add up to four serial peripherals with minimal hassle.<br />Compatible with most RS232 peripherals, the Manhattan PCI Express Serial Card with 5V power output includes an adapter that allows you to connect up to four independent serial devices — modems, barcode readers, printers, and more — through a single PCI card. It is ideal for point-of-sale applications as it helps eliminate power supplies from other connected peripherals, reduce clutter, and improve reliability. Its high-speed 16C950 UART DB9 serial COM ports are fully compatible with PCI IRQ sharing, even if accessed simultaneously, to help save valuable resources for other expansion cards.<br /><br />Easy installation

Compatibility with Windows XP/Vista/7/8.1/10 and Linux version 2.6.31 or later, plug-and-play connectivity, and automatic IRQ and IO address selection make installation easy and help avoid configuration conflicts with other devices.

Technical Specifications

General Features
Brand	Manhattan
Item	Serial Card
Standards and Certifications	• CE • FCC • RoHS • WEEE • PCIe 2.0 Gen 1
Ports	Four DB9 Male ports
Performance	Up to 230 kbps
Chipset:	Exar XR17V354
Operation	at 3.3 V
Transmission	256-byte receive FIFO
Complement and compatibility	with 16450 and 16550 models
Bus	PCI Express x1 • Bus speed: 2.5 Gbps • PCI Express 2.0 • PCI 1.2 (Power Management)
System Requirements	• Windows 7/8.1/10 • Linux version 2.6.31 or higher • System with PCI Express capability and available PCI Express slot with PCI panel • CD-ROM drive
Dimensions	12 cm x 9.4 cm x 2 cm
Weight	29.5 g
